| Product Number | Bit Rate | FC-PI | Power Budget |
Spacing / Wavelength | Package | Temperature Range |
TX Power | RX Sens. | Data Sheet |
| SPS-8350W-DXXG | 4/2/1 Gb/s | 400/200/100 | >20 dB | 100GHz / DWDM | SFP with DMI | 0 ~ 70°C | 5 to 2 dBm | -18 dBm |  |
| SPS-8350BW-DXXG | 4/2/1 Gb/s | 400/200/100 | >20 dB | 100GHz / DWDM | SFP with DMI | -10 ~ 85°C | 5 to 2 dBm | -18 dBm | |
| SPS-8350AW-DXXG | 4/2/1 Gb/s | 400/200/100 | >20 dB | 100GHz / DWDM | SFP with DMI | -40 ~ 85°C | 5 to 2 dBm | -18 dBm | |
| SPS-8380W-DXXG | 4/2/1 Gb/s | 400/200/100 | >26 dB | 100GHz / DWDM | SFP with DMI | 0 ~ 70°C | 5 to 0 dBm | -26 dBm | |
| SPS-8380BW-DXXG | 4/2/1 Gb/s | 400/200/100 | >26 dB | 100GHz / DWDM | SFP with DMI | -10 ~ 85°C | 5 to 0 dBm | -26 dBm | |
| SPS-8380AW-DXXG | 4/2/1 Gb/s | 400/200/100 | >26 dB | 100GHz / DWDM | SFP with DMI | -40 ~ 85°C | 5 to 0 dBm | -26 dBm | |
| SPS-83120W-DXXG | 4/2/1 Gb/s | 400/200/100 | >26 dB | 100GHz / DWDM | SFP with DMI | 0 ~ 70°C | 7 to 4 dBm | -26 dBm | |
| SPS-83120BW-DXXG | 4/2/1 Gb/s | 400/200/100 | >26 dB | 100GHz / DWDM | SFP with DMI | -10 ~ 85°C | 7 to 4 dBm | -26 dBm | |
| SPS-83120AW-DXXG | 4/2/1 Gb/s | 400/200/100 | >26 dB | 100GHz / DWDM | SFP with DMI | -40 ~ 85°C | 7 to 4 dBm | -26 dBm | |
PRODUCTS
Fibre Channel
4Gb/s DWDM
