IEEE C37.94

IEEE C37.94

1 / 1
SFP MM LC
Product Number Bit Rate SONET
/SDH		 Reach Wavelength Package Temperature
Range		 TX Power RX Sens. Data
Sheet
SPM-3102W-64G 64K-2M b/s   0~2000 m 850 nm LC SFP    0 ~ 70°C -11 to -19 dBm* -32 dBm
SPM-3102BW-64G 64K-2M b/s   0~2000 m 850 nm LC SFP -10 ~ 85°C -11 to -19 dBm* -32 dBm
SPM-3102AW-64G 64K-2M b/s   0~2000 m 850 nm LC SFP -40 ~ 85°C -11 to -19 dBm* -32 dBm
* Power coupled to 62.5/125 µm MMF. For the 50/125 µm MMF, the coupled power is -11 to -23 dBm.


SFP SM LC
Product Number Bit Rate SONET
/SDH		 Reach Wavelength Package Temperature
Range		 TX Power RX Sens. Data
Sheet
SPS-3120W-64G 64K-2M b/s     20 km 1310 nm LC SFP    0 ~ 70°C -11 to -19 dBm -32 dBm
SPS-3120BW-64G 64K-2M b/s     20 km 1310 nm LC SFP -10 ~ 85°C -11 to -19 dBm -32 dBm
SPS-3120AW-64G 64K-2M b/s     20 km 1310 nm LC SFP -40 ~ 85°C -11 to -19 dBm -32 dBm
SPS-3130W-64G 64K-2M b/s     30 km 1310 nm LC SFP    0 ~ 70°C   -8 to -14 dBm -34 dBm
SPS-3130BW-64G 64K-2M b/s     30 km 1310 nm LC SFP -10 ~ 85°C   -8 to -14 dBm -34 dBm
SPS-3130AW-64G 64K-2M b/s     30 km 1310 nm LC SFP -40 ~ 85°C   -8 to -14 dBm -34 dBm
SPS-3160W-64G 64K-2M b/s     60 km 1310 nm LC SFP    0 ~ 70°C    4 to    0 dBm -34 dBm
SPS-3160BW-64G 64K-2M b/s     60 km 1310 nm LC SFP -10 ~ 85°C    4 to    0 dBm -34 dBm
SPS-3160AW-64G 64K-2M b/s     60 km 1310 nm LC SFP -40 ~ 85°C    4 to    0 dBm -34 dBm
SPS-33120W-64G 64K-2M b/s     120 km 1550 nm LC SFP    0 ~ 70°C    8 to    5 dBm -34 dBm
SPS-33120BW-64G 64K-2M b/s     120 km 1550 nm LC SFP -10 ~ 85°C    8 to    5 dBm -34 dBm
SPS-33120AW-64G 64K-2M b/s     120 km 1550 nm LC SFP -40 ~ 85°C    8 to    5 dBm -34 dBm
