| Product Number | Type | Bit Rate | TX1 | TX2 | Package | Temperature Range |
Data Sheet |
||
| Wavelength | Power | Wavelength | Power | ||||||
| SPS-2310VMW-CXXCYYG* | 2-TX | Up to 12 Gb/s | CWDM | 5 to 0 dBm | CWDM | 5 to 0 dBm | LC SFP+ with DMI | 0 ~ 70 °C |  |
| SPS-2310AVMW-CXXCYYG* | 2-TX | Up to 12 Gb/s | CWDM | 5 to 0 dBm | CWDM | 5 to 0 dBm | LC SFP+ with DMI | -40 ~ 85 °C | |
| SPS-2340VMW-CXXCYYG* | 2-TX | Up to 12 Gb/s | CWDM | 8 to 4 dBm | CWDM | 8 to 4 dBm | LC SFP+ with DMI | 0 ~ 70 °C | |
| SPS-2340AVMW-CXXCYYG* | 2-TX | Up to 12 Gb/s | CWDM | 8 to 4 dBm | CWDM | 8 to 4 dBm | LC SFP+ with DMI | -40 ~ 85 °C | |
| SPS-2310VMW-CXXG* | 1-TX | Up to 12 Gb/s | CWDM | 5 to 0 dBm | LC SFP+ with DMI | 0 ~ 70 °C | |
||
| SPS-2310AVMW-CXXG* | 1-TX | Up to 12 Gb/s | CWDM | 5 to 0 dBm | LC SFP+ with DMI | -40 ~ 85 °C | |
||
| SPS-2340VMW-CXXG* | 1-TX | Up to 12 Gb/s | CWDM | 8 to 4 dBm | LC SFP+ with DMI | 0 ~ 70 °C | |
||
| SPS-2340AVMW-CXXG* | 1-TX | Up to 12 Gb/s | CWDM | 8 to 4 dBm | LC SFP+ with DMI | -40 ~ 85 °C | |
||
| SPS-2312VMW-CXXCYYG* | 2-TX | Up to 12 Gb/s | CWDM | 5 to 0 dBm | CWDM | 5 to 0 dBm | LC SFP+ with DMI | 0 ~ 70 °C | |
| SPS-2312AVMW-CXXCYYG* | 2-TX | Up to 12 Gb/s | CWDM | 5 to 0 dBm | CWDM | 5 to 0 dBm | LC SFP+ with DMI | -40 ~ 85 °C | |
| SPS-2342VMW-CXXCYYG* | 2-TX | Up to 12 Gb/s | CWDM | 8 to 4 dBm | CWDM | 8 to 4 dBm | LC SFP+ with DMI | 0 ~ 70 °C | |
| SPS-2342AVMW-CXXCYYG* | 2-TX | Up to 12 Gb/s | CWDM | 8 to 4 dBm | CWDM | 8 to 4 dBm | LC SFP+ with DMI | -40 ~ 85 °C | |
| SPS-2312VMW-CXXG* | 1-TX | Up to 12 Gb/s | CWDM | 5 to 0 dBm | LC SFP+ with DMI | 0 ~ 70 °C | |
||
| SPS-2312AVMW-CXXG* | 1-TX | Up to 12 Gb/s | CWDM | 5 to 0 dBm | LC SFP+ with DMI | -40 ~ 85 °C | |
||
| SPS-2342VMW-CXXG* | 1-TX | Up to 12 Gb/s | CWDM | 8 to 4 dBm | LC SFP+ with DMI | 0 ~ 70 °C | |
||
| SPS-2342AVMW-CXXG* | 1-TX | Up to 12 Gb/s | CWDM | 8 to 4 dBm | LC SFP+ with DMI | -40 ~ 85 °C | |
||
CWDM : 12Gb/s SM Video SFP+ 1-Transmitter + 1-Receiver
| Product Number | Type | Bit Rate | Power Budget | Package | Temperature Range |
Data Sheet |
| SPS-2316VMW-CXX1RG | 1-TX + 1-RX | Up to 12 Gb/s | >11 dB | LC SFP+ with DMI | 0 ~ 70 °C | |
| SPS-2316AVMW-CXX1RG | 1-TX + 1-RX | Up to 12 Gb/s | >11 dB | LC SFP+ with DMI | -40 ~ 85 °C | |
| SPS-2346VMW-CXX1RG | 1-TX + 1-RX | Up to 12 Gb/s | >15 dB | LC SFP+ with DMI | 0 ~ 70 °C | |
| SPS-2346AVMW-CXX1RG | 1-TX + 1-RX | Up to 12 Gb/s | >15 dB | LC SFP+ with DMI | -40 ~ 85 °C | |
| SPS-2317VMW-CXX1RG | 1-TX + 1-RX | Up to 12 Gb/s | >11 dB | LC SFP+ with DMI | 0 ~ 70 °C | |
| SPS-2317AVMW-CXX1RG | 1-TX + 1-RX | Up to 12 Gb/s | >11 dB | LC SFP+ with DMI | -40 ~ 85 °C | |
| SPS-2347VMW-CXX1RG | 1-TX + 1-RX | Up to 12 Gb/s | >15 dB | LC SFP+ with DMI | 0 ~ 70 °C | |
| SPS-2347AVMW-CXX1RG | 1-TX + 1-RX | Up to 12 Gb/s | >15 dB | LC SFP+ with DMI | -40 ~ 85 °C | |
CWDM : 12Gb/s SM Video SFP+ Transceiver (same pin assignment as SFP+ MSA)
| Product Number | Bit Rate | Power Budget | Package | Temperature Range |
Data Sheet |
| SPS-2316VMW-CXX0G | Up to 12 Gb/s | >11 dB | LC SFP+ with DMI | 0 ~ 70 °C | |
| SPS-2316AVMW-CXX0G | Up to 12 Gb/s | >11 dB | LC SFP+ with DMI | -40 ~ 85 °C | |
| SPS-2346VMW-CXX0G | Up to 12 Gb/s | >15 dB | LC SFP+ with DMI | 0 ~ 70 °C | |
| SPS-2346AVMW-CXX0G | Up to 12 Gb/s | >15 dB | LC SFP+ with DMI | -40 ~ 85 °C | |
| SPS-2317VMW-CXX0G | Up to 12 Gb/s | >11 dB | LC SFP+ with DMI | 0 ~ 70 °C | |
| SPS-2317AVMW-CXX0G | Up to 12 Gb/s | >11 dB | LC SFP+ with DMI | -40 ~ 85 °C | |
| SPS-2347VMW-CXX0G | Up to 12 Gb/s | >15 dB | LC SFP+ with DMI | 0 ~ 70 °C | |
| SPS-2347AVMW-CXX0G | Up to 12 Gb/s | >15 dB | LC SFP+ with DMI | -40 ~ 85 °C | |
