| Product Number | Bit Rate | SONET /SDH |
Power Budget |
Spacing / Wavelength | Package | Temperature Range |
TX Power | RX Sens. | Data Sheet |
| SPS-9350W-DXXG | 2.488 Gb/s | LR-2/L-16.2 | >20 dB | 100GHz / DWDM | SFP with DMI | 0 ~ 70°C | 5 to 2 dBm | -18 dBm |  |
| SPS-9350BW-DXXG | 2.488 Gb/s | LR-2/L-16.2 | >2 0dB | 100GHz / DWDM | SFP with DMI | -10 ~ 85°C | 5 to 2 dBm | -18 dBm | |
| SPS-9350AW-DXXG | 2.488 Gb/s | LR-2/L-16.2 | >20 dB | 100GHz / DWDM | SFP with DMI | -40 ~ 85°C | 5 to 2 dBm | -18 dBm | |
| SPS-9380W-DXXG | 2.488 Gb/s | >28 dB | 100GHz / DWDM | SFP with DMI | 0 ~ 70°C | 5 to 0 dBm | -28 dBm | |
|
| SPS-9380BW-DXXG | 2.488 Gb/s | >28 dB | 100GHz / DWDM | SFP with DMI | -10 ~ 85°C | 5 to 0 dBm | -28 dBm | |
|
| SPS-9380AW-DXXG | 2.488 Gb/s | >28 dB | 100GHz / DWDM | SFP with DMI | -40 ~ 85°C | 5 to 0 dBm | -28 dBm | |
|
| SPS-93120W-DXXG | 2.488 Gb/s | >32 dB | 100GHz / DWDM | SFP with DMI | 0 ~ 70°C | 7 to 4 dBm | -28 dBm | |
|
| SPS-93120BW-DXXG | 2.488 Gb/s | >32 dB | 100GHz / DWDM | SFP with DMI | -10 ~ 85°C | 7 to 4 dBm | -28 dBm | |
|
| SPS-93120AW-DXXG | 2.488 Gb/s | >32 dB | 100GHz / DWDM | SFP with DMI | -40 ~ 85°C | 7 to 4 dBm | -28 dBm | |
|
| SPS-93160W-DXXG | 2.488 Gb/s | >35 dB | 100GHz / DWDM | SFP with DMI | 0 ~ 70°C | 8 to 5 dBm | -30 dBm | |
|
| SPS-93160BW-DXXG | 2.488 Gb/s | >35 dB | 100GHz / DWDM | SFP with DMI | -10 ~ 85°C | 8 to 5 dBm | -30 dBm | |
|
| SPS-93160AW-DXXG | 2.488 Gb/s | >35 dB | 100GHz / DWDM | SFP with DMI | -40 ~ 85°C | 8 to 5 dBm | -30 dBm | |
