| Product Number | Bit Rate | SONET /SDH |
Reach | Wavelength | Package | Temperature Range |
TX Power | RX Sens. | Data Sheet |
| SPM-5101G | 622 Mb/s | SX | 0~1000 m | 1310 nm | LC SFP | 0 ~ 70°C | -12 to -19 dBm | -26 dBm |  |
| SPM-5101BG | 622 Mb/s | SX | 0~1000 m | 1310 nm | LC SFP | -10 ~ 85°C | -12 to -19 dBm | -26 dBm | |
| SPM-5101AG | 622 Mb/s | SX | 0~1000 m | 1310 nm | LC SFP | -40 ~ 85°C | -12 to -19 dBm | -26 dBm | |
| SPM-5101WG | 622 Mb/s | SX | 0~1000 m | 1310 nm | LC SFP with DMI | 0 ~ 70°C | -12 to -19 dBm | -26 dBm | |
| SPM-5101BWG | 622 Mb/s | SX | 0~1000 m | 1310 nm | LC SFP with DMI | -10 ~ 85°C | -12 to -19 dBm | -26 dBm | |
| SPM-5101AWG | 622 Mb/s | SX | 0~1000 m | 1310 nm | LC SFP with DMI | -40 ~ 85°C | -12 to -19 dBm | -26 dBm | |
SFP SM LC
| Product Number | Bit Rate | SONET /SDH |
Reach | Wavelength | Package | Temperature Range |
TX Power | RX Sens. | Data Sheet |
| SPS-5120G | 622 Mb/s | IR-1/S-4.1 | 20 km | 1310 nm | LC SFP | -10 ~ 85°C | -8 to -14 dBm | -28 dBm | |
| SPS-5120AG | 622 Mb/s | IR-1/S-4.1 | 20 km | 1310 nm | LC SFP | -40 ~ 85°C | -8 to -14 dBm | -28 dBm | |
| SPS-5140G | 622 Mb/s | LR-1/L-4.1 | 40 km | 1310 nm | LC SFP | 0 ~ 70°C | 2 to -3 dBm | -28 dBm | |
| SPS-5140BG | 622 Mb/s | LR-1/L-4.1 | 40 km | 1310 nm | LC SFP | -10 ~ 85°C | 2 to -3 dBm | -28 dBm | |
| SPS-5140AG | 622 Mb/s | LR-1/L-4.1 | 40 km | 1310 nm | LC SFP | -40 ~ 85°C | 2 to -3 dBm | -28 dBm | |
| SPS-5380G | 622 Mb/s | LR-2/L-4.2 | 80 km | 1550 nm DFB | LC SFP | 0 ~ 70°C | 2 to -3 dBm | -29 dBm | |
| SPS-5380BG | 622 Mb/s | LR-2/L-4.2 | 80 km | 1550 nm DFB | LC SFP | -10 ~ 85°C | 2 to -3 dBm | -29 dBm | |
| SPS-5380AG | 622 Mb/s | LR-2/L-4.2 | 80 km | 1550 nm DFB | LC SFP | -40 ~ 85°C | 2 to -3 dBm | -29 dBm | |
| SPS-53120G | 622 Mb/s | 120 km | 1550 nm DFB | LC SFP | 0 ~ 70°C | 5 to 0 dBm | -34 dBm | |
|
| SPS-53120BG | 622 Mb/s | 120 km | 1550 nm DFB | LC SFP | -10 ~ 85°C | 5 to 0 dBm | -34 dBm | |
|
| SPS-53120AG | 622 Mb/s | 120 km | 1550 nm DFB | LC SFP | -40 ~ 85°C | 5 to 0 dBm | -34 dBm | |
|
| SPS-53160G | 622 Mb/s | 160 km | 1550 nm DFB | LC SFP | 0 ~ 70°C | 5 to 1 dBm | -37 dBm | |
|
| SPS-53160BG | 622 Mb/s | 160 km | 1550 nm DFB | LC SFP | -10 ~ 85°C | 5 to 1 dBm | -37 dBm | |
|
| SPS-53160AG | 622 Mb/s | 160 km | 1550 nm DFB | LC SFP | -40 ~ 85°C | 5 to 1 dBm | -37 dBm | |
|
| SPS-53200G | 622 Mb/s | 200 km | 1550 nm DFB | LC SFP | 0 ~ 70°C | 6 to 3 dBm | -38 dBm | |
|
| SPS-53200BG | 622 Mb/s | 200 km | 1550 nm DFB | LC SFP | -10 ~ 85°C | 6 to 3 dBm | -38 dBm | |
|
| SPS-53200AG | 622 Mb/s | 200 km | 1550 nm DFB | LC SFP | -40 ~ 85°C | 6 to 3 dBm | -38 dBm | |
|
| SPS-5120WG | 622 Mb/s | IR-1/S-4.1 | 20 km | 1310 nm | LC SFP with DMI | -10 ~ 85°C | -8 to -14 dBm | -28 dBm | |
| SPS-5120AWG | 622 Mb/s | IR-1/S-4.1 | 20 km | 1310 nm | LC SFP with DMI | -40 ~ 85°C | -8 to -14 dBm | -28 dBm | |
| SPS-5140WG | 622 Mb/s | LR-1/L-4.1 | 40 km | 1310 nm | LC SFP with DMI | 0 ~ 70°C | 2 to -3 dBm | -28 dBm | |
| SPS-5140BWG | 622 Mb/s | LR-1/L-4.1 | 40 km | 1310 nm | LC SFP with DMI | -10 ~ 85°C | 2 to -3 dBm | -28 dBm | |
| SPS-5140AWG | 622 Mb/s | LR-1/L-4.1 | 40 km | 1310nm | LC SFP with DMI | -40 ~ 85°C | 2 to -3 dBm | -28 dBm | |
| SPS-5380WG | 622 Mb/s | LR-2/L-4.2 | 80 km | 1550 nm DFB | LC SFP with DMI | 0 ~ 70°C | 2 to -3 dBm | -29 dBm | |
| SPS-5380BWG | 622 Mb/s | LR-2/L-4.2 | 80 km | 1550 nm DFB | LC SFP with DMI | -10 ~ 85°C | 2 to -3 dBm | -29 dBm | |
| SPS-5380AWG | 622 Mb/s | LR-2/L-4.2 | 80 km | 1550 nm DFB | LC SFP with DMI | -40 ~ 85°C | 2 to -3 dBm | -29 dBm | |
| SPS-53120WG | 622 Mb/s | 120 km | 1550 nm DFB | LC SFP with DMI | 0 ~ 70°C | 5 to 0 dBm | -34 dBm | |
|
| SPS-53120BWG | 622 Mb/s | 120 km | 1550 nm DFB | LC SFP with DMI | -10 ~ 85°C | 5 to 0 dBm | -34 dBm | |
|
| SPS-53120AWG | 622 Mb/s | 120 km | 1550 nm DFB | LC SFP with DMI | -40 ~ 85°C | 5 to 0 dBm | -34 dBm | |
|
| SPS-53160WG | 622 Mb/s | 160 km | 1550 nm DFB | LC SFP with DMI | 0 ~ 70°C | 5 to 1 dBm | -37 dBm | |
|
| SPS-53160BWG | 622 Mb/s | 160 km | 1550 nm DFB | LC SFP with DMI | -10 ~ 85°C | 5 to 1 dBm | -37 dBm | |
|
| SPS-53160AWG | 622 Mb/s | 160 km | 1550 nm DFB | LC SFP with DMI | -40 ~ 85°C | 5 to 1 dBm | -37 dBm | |
|
| SPS-53200WG | 622 Mb/s | 200 km | 1550 nm DFB | LC SFP with DMI | 0 ~ 70°C | 6 to 3 dBm | -38 dBm | |
|
| SPS-53200BWG | 622 Mb/s | 200 km | 1550 nm DFB | LC SFP with DMI | -10 ~ 85°C | 6 to 3 dBm | -38 dBm | |
|
| SPS-53200AWG | 622 Mb/s | 200 km | 1550 nm DFB | LC SFP with DMI | -40 ~ 85°C | 6 to 3 dBm | -38 dBm | |
CWDM SFP SM LC
| Product NumberBit Rate | Bit Rate | SONET /SDH |
Power Budget | Wavelength | Package | Temperature Range |
TX Power | RX Sens. | Data Sheet |
| SPS-5380-CXX0G | 622 Mb/s | >29 dB | CWDM* | LC SFP | 0 ~ 70°C | 5 to 0 dBm | -29 dBm | |
|
| SPS-5380B-CXX0G | 622 Mb/s | >29 dB | CWDM* | LC SFP | -5 ~ 85°C | 5 to 0 dBm | -29 dBm | |
|
| SPS-5380A-CXX0G | 622 Mb/s | >29 dB | CWDM* | LC SFP | -40 ~ 85°C | 5 to 0 dBm | -29 dBm | |
|
| SPS-53120-CXX0G | 622 Mb/s | >34 dB | CWDM* | LC SFP | 0 ~ 70°C | 5 to 0 dBm | -34 dBm | |
|
| SPS-53120B-CXX0G | 622 Mb/s | >34 dB | CWDM* | LC SFP | -5 ~ 85°C | 5 to 0 dBm | -34 dBm | |
|
| SPS-53120A-CXX0G | 622 Mb/s | >34 dB | CWDM* | LC SFP | -40 ~ 85°C | 5 to 0 dBm | -34 dBm | |
|
| SPS-53160-CXX0G | 622 Mb/s | >38 dB | CWDM* | LC SFP | 0 ~ 70°C | 5 to 1 dBm | -37 dBm | |
|
| SPS-53160B-CXX0G | 622 Mb/s | >38 dB | CWDM* | LC SFP | -5 ~ 85°C | 5 to 1 dBm | -37 dBm | |
|
| SPS-53160A-CXX0G | 622 Mb/s | >38 dB | CWDM* | LC SFP | -40 ~ 85°C | 5 to 1 dBm | -37 dBm | |
|
| SPS-53200-CXX0G | 622 Mb/s | >41 dB | CWDM* | LC SFP | 0 ~ 70°C | 6 to 3 dBm | -38 dBm | |
|
| SPS-53200B-CXX0G | 622 Mb/s | >41 dB | CWDM* | LC SFP | -5 ~ 85°C | 6 to 3 dBm | -38 dBm | |
|
| SPS-53200A-CXX0G | 622 Mb/s | >41 dB | CWDM* | LC SFP | -40 ~ 85°C | 6 to 3 dBm | -38 dBm | |
|
| SPS-5380W-CXX0G | 622 Mb/s | >29 dB | CWDM* | LC SFP with DMI | 0 ~ 70°C | 5 to 0 dBm | -29 dBm | |
|
| SPS-5380BW-CXX0G | 622 Mb/s | >29 dB | CWDM* | LC SFP with DMI | -5 ~ 85°C | 5 to 0 dBm | -29 dBm | |
|
| SPS-5380AW-CXX0G | 622 Mb/s | >29 dB | CWDM* | LC SFP with DMI | -40 ~ 85°C | 5 to 0 dBm | -29 dBm | |
|
| SPS-53120W-CXX0G | 622 Mb/s | >34 dB | CWDM* | LC SFP with DMI | 0 ~ 70°C | 5 to 0 dBm | -34 dBm | |
|
| SPS-53120BW-CXX0G | 622 Mb/s | >34 dB | CWDM* | LC SFP with DMI | -5 ~ 85°C | 5 to 0 dBm | -34 dBm | |
|
| SPS-53120AW-CXX0G | 622 Mb/s | >34 dB | CWDM* | LC SFP with DMI | -40 ~ 85°C | 5 to 0 dBm | -34 dBm | |
|
| SPS-53160W-CXX0G | 622 Mb/s | >38 dB | CWDM* | LC SFP with DMI | 0 ~ 70°C | 5 to 1 dBm | -37 dBm | |
|
| SPS-53160BW-CXX0G | 622 Mb/s | >38 dB | CWDM* | LC SFP with DMI | -5 ~ 85°C | 5 to 1 dBm | -37 dBm | |
|
| SPS-53160AW-CXX0G | 622 Mb/s | >38 dB | CWDM* | LC SFP with DMI | -40 ~ 85°C | 5 to 1 dBm | -37 dBm | |
|
| SPS-53200W-CXX0G | 622 Mb/s | >41 dB | CWDM* | LC SFP with DMI | 0 ~ 70°C | 6 to 3 dBm | -38 dBm | |
|
| SPS-53200BW-CXX0G | 622 Mb/s | >41 dB | CWDM* | LC SFP with DMI | -5 ~ 85°C | 6 to 3 dBm | -38 dBm | |
|
| SPS-53200AW-CXX0G | 622 Mb/s | >41 dB | CWDM* | LC SFP with DMI | -40 ~ 85°C | 6 to 3 dBm | -38 dBm | |
DWDM SFP SM LC
| Product Number | Bit Rate | SONET /SDH |
Power Budget | Spacing / Wavelength | Package | Temperature Range |
TX Power | RX Sens. | Data Sheet |
| SPS-5380W-DXXG | 622 Mb/s | LR-2/L-4.2 | >29 dB | 100GHz with DWDM | SFP with DMI | 0 ~ 70°C | 5 to 0 dBm | -29 dBm | |
| SPS-5380BW-DXXG | 622 Mb/s | LR-2/L-4.2 | >29 dB | 100GHz with DWDM | SFP with DMI | -10 ~ 85°C | 5 to 0 dBm | -29 dBm | |
| SPS-5380AW-DXXG | 622 Mb/s | LR-2/L-4.2 | >29 dB | 100GHz with DWDM | SFP with DMI | -40 ~ 85°C | 5 to 0 dBm | -29 dBm | |
| SPS-53120W-DXXG | 622 Mb/s | >34 dB | 100GHz with DWDM | SFP with DMI | 0 ~ 70°C | 5 to 0 dBm | -34 dBm | |
|
| SPS-53120BW-DXXG | 622 Mb/s | >34 dB | 100GHz with DWDM | SFP with DMI | -10 ~ 85°C | 5 to 0 dBm | -34 dBm | |
|
| SPS-53120AW-DXXG | 622 Mb/s | >34 dB | 100GHz with DWDM | SFP with DMI | -40 ~ 85°C | 5 to 0 dBm | -34 dBm | |
|
| SPS-53160W-DXXG | 622 Mb/s | >39 dB | 100GHz with DWDM | SFP with DMI | 0 ~ 70°C | 5 to 2 dBm | -37 dBm | |
|
| SPS-53160BW-DXXG | 622 Mb/s | >39 dB | 100GHz with DWDM | SFP with DMI | -10 ~ 85°C | 5 to 2 dBm | -37 dBm | |
|
| SPS-53160AW-DXXG | 622 Mb/s | >39 dB | 100GHz with DWDM | SFP with DMI | -40 ~ 85°C | 5 to 2 dBm | -37 dBm | |
|
| SPS-53200W-DXXG | 622 Mb/s | >42 dB | 100GHz with DWDM | SFP with DMI | 0 ~ 70°C | 7 to 4 dBm | -38 dBm | |
|
| SPS-53200BW-DXXG | 622 Mb/s | >42 dB | 100GHz with DWDM | SFP with DMI | -10 ~ 85°C | 7 to 4 dBm | -38 dBm | |
|
| SPS-53200AW-DXXG | 622 Mb/s | >42 dB | 100GHz with DWDM | SFP with DMI | -40 ~ 85°C | 7 to 4 dBm | -38 dBm | |
