| Product Number | Bit Rate | 1000 BASE |
Reach | Wavelength | Package | Temperature Range |
TX Power | RX Sens. | Data Sheet |
| SPM-7101G | 1.25 Gb/s | SX | 300/550 m | 850 nm | LC SFP | 0 ~ 70°C | -3 to -9 dBm | -17 dBm |  |
| SPM-7100G | 1.25 Gb/s | SX | 300/550 m | 850 nm | LC SFP | -10 ~ 85°C | -3 to -9 dBm | -17 dBm | |
| SPM-7100AG | 1.25 Gb/s | SX | 300/550 m | 850 nm | LC SFP | -40 ~ 85°C | -3 to -9 dBm | -17 dBm | |
| SPM-7101WG | 1.25 Gb/s | SX | 300/550 m | 850 nm | LC SFP with DMI | 0 ~ 70°C | -3 to -9 dBm | -17 dBm | |
| SPM-7100WG | 1.25 Gb/s | SX | 300/550 m | 850 nm | LC SFP with DMI | -10 ~ 85°C | -3 to -9 dBm | -17 dBm | |
| SPM-7100AWG | 1.25 Gb/s | SX | 300/550 m | 850 nm | LC SFP with DMI | -40 ~ 85°C | -3 to -9 dBm | -17 dBm | |
SFP SM LC
| Product Number | Bit Rate | SONET /SDH |
Reach | Wavelength | Package | Temperature Range |
TX Power | RX Sens. | Data Sheet |
| SPS-7111G | 1.25 Gb/s | LX/LH | 10 km | 1310 nm | LC SFP | 0 ~ 70°C | -3 to -9.5 dBm | -20 dBm | |
| SPS-7110G | 1.25 Gb/s | LX/LH | 10 km | 1310 nm | LC SFP | -10 ~ 85°C | -3 to -9.5 dBm | -21 dBm | |
| SPS-7110AG | 1.25 Gb/s | LX/LH | 10 km | 1310 nm | LC SFP | -40 ~ 85°C | -3 to -9.5 dBm | -21 dBm | |
| SPS-7120G | 1.25 Gb/s | 20 km | 1310 nm | LC SFP | 0 ~ 70°C | -1 to -6 dBm | -22 dBm | |
|
| SPS-7120BG | 1.25 Gb/s | 20 km | 1310 nm | LC SFP | -10 ~ 85°C | -1 to -6 dBm | -22 dBm | |
|
| SPS-7120AG | 1.25 Gb/s | 20 km | 1310 nm | LC SFP | -40 ~ 85°C | -1 to -6 dBm | -22 dBm | |
|
| SPS-7130G | 1.25 Gb/s | 30 km | 1310 nm | LC SFP | 0 ~ 70°C | 0 to -5 dBm | -24 dBm | |
|
| SPS-7130BG | 1.25 Gb/s | 30 km | 1310 nm | LC SFP | -10 ~ 85°C | 0 to -5 dBm | -24 dBm | |
|
| SPS-7130AG | 1.25 Gb/s | 30 km | 1310 nm | LC SFP | -40 ~ 85°C | 0 to -5 dBm | -24 dBm | |
|
| SPS-7140G | 1.25 Gb/s | 40 km | 1310 nm DFB | LC SFP | 0 ~ 70°C | 3 to -2 dBm | -24 dBm | |
|
| SPS-7140BG | 1.25 Gb/s | 40 km | 1310 nm DFB | LC SFP | -10 ~ 85°C | 3 to -2 dBm | -24 dBm | |
|
| SPS-7140AG | 1.25 Gb/s | 40 km | 1310 nm DFB | LC SFP | -40 ~ 85°C | 3 to -2 dBm | -24 dBm | |
|
| SPS-7350G | 1.25 Gb/s | XD | 50 km | 1550 nm DFB | LC SFP | 0 ~ 70°C | 0 to -5 dBm | -24 dBm | |
| SPS-7350BG | 1.25 Gb/s | XD | 50 km | 1550 nm DFB | LC SFP | -10 ~ 85°C | 0 to -5 dBm | -24 dBm | |
| SPS-7350AG | 1.25 Gb/s | XD | 50 km | 1550 nm DFB | LC SFP | -40 ~ 85°C | 0 to -5 dBm | -24 dBm | |
| SPS-7380G | 1.25 Gb/s | ZX | 80 km | 1550 nm DFB | LC SFP | 0 ~ 70°C | 5 to 0 dBm | -24 dBm | |
| SPS-7380BG | 1.25 Gb/s | ZX | 80 km | 1550 nm DFB | LC SFP | -10 ~ 85°C | 5 to 0 dBm | -24 dBm | |
| SPS-7380AG | 1.25 Gb/s | ZX | 80 km | 1550 nm DFB | LC SFP | -40 ~ 85°C | 5 to 0 dBm | -24d Bm | |
| SPS-73120G | 1.25 Gb/s | 120 km | 1550 nm DFB | LC SFP | 0 ~ 70°C | 5 to 0 dBm | -32 dBm | |
|
| SPS-73120BG | 1.25 Gb/s | 120 km | 1550 nm DFB | LC SFP | -10 ~ 85°C | 5 to 0 dBm | -32 dBm | |
|
| SPS-73120AG | 1.25 Gb/s | 120 km | 1550 nm DFB | LC SFP | -40 ~ 85°C | 5 to 0 dBm | -32 dBm | |
|
| SPS-73160G | 1.25 Gb/s | 16 0km | 1550 nm DFB | LC SFP | 0 ~ 70°C | 5 to 1 dBm | -36 dBm | |
|
| SPS-73180G | 1.25 Gb/s | 180 km | 1550 nm DFB | LC SFP | 0 ~ 70°C | 6 to 3 dBm | -36 dBm | |
|
| SPS-73200G | 1.25 Gb/s | 200 km | 1550 nm DFB | LC SFP | 0 ~ 70°C | 8 to 5 dBm | -36 dBm | |
|
| SPS-7111WG | 1.25 Gb/s | 10 km | 1310 nm | LC SFP with DMI | 0 ~ 70°C | -3 to -9.5 dBm | -20 dBm | |
|
| SPS-7110WG | 1.25 Gb/s | 10 km | 1310 nm | LC SFP with DMI | -10 ~ 85°C | -3 to -9.5 dBm | -21 dBm | |
|
| SPS-7110AWG | 1.25 Gb/s | 10 km | 1310 nm | LC SFP with DMI | -40 ~ 85°C | -3 to -9.5 dBm | -21 dBm | |
|
| SPS-7120WG | 1.25 Gb/s | 20 km | 1310 nm | LC SFP with DMI | 0 ~ 70°C | -1 to -6 dBm | -22 dBm | |
|
| SPS-7120BWG | 1.25 Gb/s | 20 km | 1310 nm | LC SFP with DMI | -10 ~ 85°C | -1 to -6 dBm | -22 dBm | |
|
| SPS-7120AWG | 1.25 Gb/s | 20 km | 1310 nm | LC SFP with DMI | -40 ~ 85°C | -1 to -6 dBm | -22 dBm | |
|
| SPS-7130WG | 1.25 Gb/s | 30 km | 1310nm | LC SFP with DMI | 0 ~ 70°C | 0 to -5 dBm | -24 dBm | |
|
| SPS-7130BWG | 1.25 Gb/s | 30 km | 1310nm | LC SFP with DMI | -10 ~ 85°C | 0 to -5 dBm | -24 dBm | |
|
| SPS-7130AWG | 1.25 Gb/s | 30 km | 1310 nm | LC SFP with DMI | -40 ~ 85°C | 0 to -5 dBm | -24 dBm | |
|
| SPS-7140WG | 1.25 Gb/s | 40 km | 1310 nm DFB | LC SFP with DMI | 0 ~ 70°C | 3 to -2 dBm | -24 dBm | |
|
| SPS-7140BWG | 1.25 Gb/s | 40 km | 1310 nm DFB | LC SFP with DMI | -10 ~ 85°C | 3 to -2 dBm | -24 dBm | |
|
| SPS-7140AWG | 1.25 Gb/s | 40 km | 1310 nm DFB | LC SFP with DMI | -40 ~ 85°C | 3 to -2 dBm | -24 dBm | |
|
| SPS-7350WG | 1.25 Gb/s | XD | 50 km | 1550 nm DFB | LC SFP with DMI | 0 ~ 70°C | 0 to -5 dBm | -24 dBm | |
| SPS-7350BWG | 1.25 Gb/s | XD | 50 km | 1550 nm DFB | LC SFP with DMI | -10 ~ 85°C | 0 to -5 dBm | -24 dBm | |
| SPS-7350AWG | 1.25 Gb/s | XD | 50 km | 1550 nm DFB | LC SFP with DMI | -40 ~ 85°C | 0 to -5 dBm | -24 dBm | |
| SPS-7380WG | 1.25 Gb/s | ZX | 80 km | 1550 nm DFB | LC SFP with DMI | 0 ~ 70°C | 5 to 0 dBm | -24 dBm | |
| SPS-7380BWG | 1.25 Gb/s | ZX | 80 km | 1550 nm DFB | LC SFP with DMI | -10 ~ 85°C | 5 to 0 dBm | -24 dBm | |
| SPS-7380AWG | 1.25 Gb/s | ZX | 80 km | 1550 nm DFB | LC SFP with DMI | -40 ~ 85°C | 5 to 0 dBm | -24 dBm | |
| SPS-73120WG | 1.25 Gb/s | 120 km | 1550 nm DFB | LC SFP with DMI | 0 ~ 70°C | 5 to 0 dBm | -32 dBm | |
|
| SPS-73120BWG | 1.25 Gb/s | 120 km | 1550 nm DFB | LC SFP with DMI | -10 ~ 85°C | 5 to 0 dBm | -32 dBm | |
|
| SPS-73120AWG | 1.25 Gb/s | 120 km | 1550 nm DFB | LC SFP with DMI | -40 ~ 85°C | 5 to 0 dBm | -32 dBm | |
|
| SPS-73160WG | 1.25 Gb/s | 160 km | 1550 nm DFB | LC SFP with DMI | 0 ~ 70°C | 5 to 1 dBm | -36 dBm | |
|
| SPS-73160BWG | 1.25 Gb/s | 160 km | 1550 nm DFB | LC SFP with DMI | -10 ~ 85°C | 5 to 1 dBm | -36 dBm | |
|
| SPS-73160AWG | 1.25 Gb/s | 160 km | 1550 nm DFB | LC SFP with DMI | -40 ~ 85°C | 5 to 1 dBm | -36 dBm | |
|
| SPS-73180WG | 1.25 Gb/s | 180 km | 1550 nm DFB | LC SFP with DMI | 0 ~ 70°C | 6 to 3 dBm | -36 dBm | |
|
| SPS-73180BWG | 1.25 Gb/s | 180 km | 1550 nm DFB | LC SFP with DMI | -10 ~ 85°C | 6 to 3 dBm | -36 dBm | |
|
| SPS-73180AWG | 1.25 Gb/s | 180 km | 1550 nm DFB | LC SFP with DMI | -40 ~ 85°C | 6 to 3 dBm | -36 dBm | |
|
| SPS-73200WG | 1.25 Gb/s | 20 0km | 1550 nm DFB | LC SFP with DMI | 0 ~ 70°C | 8 to 5 dBm | -36 dBm | |
|
| SPS-73200BWG | 1.25 Gb/s | 200 km | 1550 nm DFB | LC SFP with DMI | -10 ~ 85°C | 8 to 5 dBm | -36 dBm | |
|
| SPS-73200AWG | 1.25 Gb/s | 200 km | 1550 nm DFB | LC SFP with DMI | -40 ~ 85°C | 8 to 5 dBm | -36 dBm | |
1.25G CWDM SFP SM LC
| Product Number | Bit Rate | SONET /SDH |
Power Budget | Wavelength | Package | Temperature Range |
TX Power | RX Sens. | Data Sheet |
| SPS-7350-CXX0G | 1.25 Gb/s | XD | >19 dB | CWDM* | LC SFP | 0 ~ 70°C | 0 to -5dBm | -24 dBm | |
| SPS-7350B-CXX0G | 1.25 Gb/s | XD | >19 dB | CWDM* | LC SFP | -5 ~ 85°C | 0 to -5dBm | -24 dBm | |
| SPS-7350A-CXX0G | 1.25 Gb/s | XD | >19 dB | CWDM* | LC SFP | -40 ~ 85°C | 0 to -5 dBm | -24 dBm | |
| SPS-7380-CXX0G | 1.25 Gb/s | ZX | >24 dB | CWDM* | LC SFP | 0 ~ 70°C | 5 to 0 dBm | -24 dBm | |
| SPS-7380B-CXX0G | 1.25 Gb/s | ZX | >24 dB | CWDM* | LC SFP | -5 ~ 85°C | 5 to 0 dBm | -24 dBm | |
| SPS-7380A-CXX0G | 1.25 Gb/s | ZX | >24 dB | CWDM* | LC SFP | -40 ~ 85°C | 5 to 0 dBm | -24 dBm | |
| SPS-7385-CXX0G | 1.25 Gb/s | >27 dB | CWDM* | LC SFP | 0 ~ 70°C | 5 to 0 dBm | -27 dBm | |
|
| SPS-7385B-CXX0G | 1.25 Gb/s | >27 dB | CWDM* | LC SFP | -5 ~ 85°C | 5 to 0 dBm | -27 dBm | |
|
| SPS-7385A-CXX0G | 1.25 Gb/s | >27 dB | CWDM* | LC SFP | -40 ~ 85°C | 5 to 0 dBm | -27 dBm | |
|
| SPS-73120-CXX0G | 1.25 Gb/s | >32 dB | CWDM* | LC SFP | 0 ~ 70°C | 5 to 0 dBm | -32 dBm | |
|
| SPS-73120B-CXX0G | 1.25 Gb/s | >32 dB | CWDM* | LC SFP | -5 ~ 85°C | 5 to 0dBm | -32 dBm | |
|
| SPS-73120A-CXX0G | 1.25 Gb/s | >32 dB | CWDM* | LC SFP | -40 ~ 85°C | 5 to 0 dBm | -32 dBm | |
|
| SPS-73160-CXX0G | 1.25 Gb/s | >37 dB | CWDM* | LC SFP | 0 ~ 70°C | 5 to 1 dBm | -36 dBm | |
|
| SPS-73160B-CXX0G | 1.25 Gb/s | >37 dB | CWDM* | LC SFP | -5 ~ 85°C | 5 to 1 dBm | -36 dBm | |
|
| SPS-73160A-CXX0G | 1.25 Gb/s | >37 dB | CWDM* | LC SFP | -40 ~ 85°C | 5 to 1 dBm | -36 dBm | |
|
| SPS-73180-CXX0G | 1.25 Gb/s | >39 dB | CWDM* | LC SFP | 0 ~ 70°C | 6 to 3 dBm | -36 dBm | |
|
| SPS-73180B-CXX0G | 1.25 Gb/s | >39 dB | CWDM* | LC SFP | -5 ~ 85°C | 6 to 3 dBm | -36 dBm | |
|
| SPS-73180A-CXX0G | 1.25 Gb/s | >39 dB | CWDM* | LC SFP | -40 ~ 85°C | 6 to 3 dBm | -36 dBm | |
|
| SPS-73200-CXX0G | 1.25 Gb/s | >41 dB | CWDM* | LC SFP | 0 ~ 70°C | 8 to 5 dBm | -36 dBm | |
|
| SPS-73200B-CXX0G | 1.25 Gb/s | >41 dB | CWDM* | LC SFP | -5 ~ 85°C | 8 to 5 dBm | -36 dBm | |
|
| SPS-73200A-CXX0G | 1.25 Gb/s | >41dB | CWDM* | LC SFP | -40 ~ 85°C | 8 to 5 dBm | -36 dBm | |
|
| SPS-7350W-CXX0G | 1.25 Gb/s | XD | >19 dB | CWDM* | LC SFP with DMI | 0 ~ 70°C | 0 to -5 dBm | -24 dBm | |
| SPS-7350BW-CXX0G | 1.25 Gb/s | XD | >19 dB | CWDM* | LC SFP with DMI | -5 ~ 85°C | 0 to -5 dBm | -24 dBm | |
| SPS-7350AW-CXX0G | 1.25 Gb/s | XD | >19 dB | CWDM* | LC SFP with DMI | -40 ~ 85°C | 0 to -5 dBm | -24 dBm | |
| SPS-7380W-CXX0G | 1.25 Gb/s | ZX | >24 dB | CWDM* | LC SFP with DMI | 0 ~ 70°C | 5 to 0 dBm | -24 dBm | |
| SPS-7380BW-CXX0G | 1.25 Gb/s | ZX | >24 dB | CWDM* | LC SFP with DMI | -5 ~ 85°C | 5 to 0 dBm | -24 dBm | |
| SPS-7380AW-CXX0G | 1.25 Gb/s | ZX | >24 dB | CWDM* | LC SFP with DMI | -40 ~ 85°C | 5 to 0 dBm | -24 dBm | |
| SPS-7385W-CXX0G | 1.25 Gb/s | >27 dB | CWDM* | LC SFP with DMI | 0 ~ 70°C | 5 to 0 dBm | -27 dBm | |
|
| SPS-7385BW-CXX0G | 1.25 Gb/s | >27 dB | CWDM* | LC SFP with DMI | -5 ~ 85°C | 5 to 0 dBm | -27 dBm | |
|
| SPS-7385AW-CXX0G | 1.25 Gb/s | >27 dB | CWDM* | LC SFP with DMI | -40 ~ 85°C | 5 to 0 dBm | -27 dBm | |
|
| SPS-73120W-CXX0G | 1.25 Gb/s | >32 dB | CWDM* | LC SFP with DMI | 0 ~ 70°C | 5 to 0 dBm | -32 dBm | |
|
| SPS-73120BW-CXX0G | 1.25 Gb/s | >32 dB | CWDM* | LC SFP with DMI | -5 ~ 85°C | 5 to 0 dBm | -32 dBm | |
|
| SPS-73120AW-CXX0G | 1.25 Gb/s | >32 dB | CWDM* | LC SFP with DMI | -40 ~ 85°C | 5 to 0 dBm | -32 dBm | |
|
| SPS-73160W-CXX0G | 1.25 Gb/s | >37 dB | CWDM* | LC SFP with DMI | 0 ~ 70°C | 5 to 1 dBm | -36 dBm | |
|
| SPS-73160BW-CXX0G | 1.25 Gb/s | >37 dB | CWDM* | LC SFP with DMI | -5 ~ 85°C | 5 to 1 dBm | -36 dBm | |
|
| SPS-73160AW-CXX0G | 1.25 Gb/s | >37 dB | CWDM* | LC SFP with DMI | -40 ~ 85°C | 5 to 1 dBm | -36 dBm | |
|
| SPS-73180W-CXX0G | 1.25 Gb/s | >39 dB | CWDM* | LC SFP with DMI | 0 ~ 70°C | 6 to 3 dBm | -36 dBm | |
|
| SPS-73180BW-CXX0G | 1.25 Gb/s | >39 dB | CWDM* | LC SFP with DMI | -5 ~ 85°C | 6 to 3dBm | -36 dBm | |
|
| SPS-73180AW-CXX0G | 1.25 Gb/s | >39 dB | CWDM* | LC SFP with DMI | -40 ~ 85°C | 6 to 3 dBm | -36 dBm | |
|
| SPS-73200W-CXX0G | 1.25 Gb/s | >41 dB | CWDM* | LC SFP with DMI | 0 ~ 70°C | 8 to 5 dBm | -36 dBm | |
|
| SPS-73200BW-CXX0G | 1.25 Gb/s | >41 dB | CWDM* | LC SFP with DMI | -5 ~ 85°C | 8 to 5 dBm | -36 dBm | |
|
| SPS-73200AW-CXX0G | 1.25 Gb/s | >41 dB | CWDM* | LC SFP with DMI | -40 ~ 85°C | 8 to 5 dBm | -36 dBm | |
DWDM SFP SM LC
| Product Number | Bit Rate | 1000 BASE |
Power Budget | Spacing / Wavelength | Package | Temperature Range |
TX Power | RX Sens. | Data Sheet |
| SPS-7350W-DXXG | 1.25 Gb/s | XD | >19 dB | 100GHz with DWDM | SFP with DMI | 0 ~ 70°C | 0 to -5 dBm | -24 dBm | |
| SPS-7350BW-DXXG | 1.25 Gb/s | XD | >19 dB | 100GHz with DWDM | SFP with DMI | -10 ~ 85°C | 0 to -5 dBm | -24 dBm | |
| SPS-7350AW-DXXG | 1.25 Gb/s | XD | >19 dB | 100GHz with DWDM | SFP with DMI | -40 ~ 85°C | 0 to -5 dBm | -24 dBm | |
| SPS-7380W-DXXG | 1.25 Gb/s | ZX | >26 dB | 100GHz with DWDM | SFP with DMI | 0 ~ 70°C | 5 to 2 dBm | -24 dBm | |
| SPS-7380BW-DXXG | 1.25 Gb/s | ZX | >26 dB | 100GHz with DWDM | SFP with DMI | -10 ~ 85°C | 5 to 2 dBm | -24 dBm | |
| SPS-7380AW-DXXG | 1.25 Gb/s | ZX | >26 dB | 100GHz with DWDM | SFP with DMI | -40 ~ 85°C | 5 to 2 dBm | -24 dBm | |
| SPS-73120W-DXXG | 1.25 Gb/s | >32 dB | 100GHz with DWDM | SFP with DMI | 0 ~ 70°C | 5 to 0 dBm | -32 dBm | |
|
| SPS-73120BW-DXXG | 1.25 Gb/s | >32 dB | 100GHz with DWDM | SFP with DMI | -10 ~ 85°C | 5 to 0 dBm | -32 dBm | |
|
| SPS-73120AW-DXXG | 1.25 Gb/s | >32 dB | 100GHz with DWDM | SFP with DMI | -40 ~ 85°C | 5 to 0 dBm | -32 dBm | |
|
| SPS-73160W-DXXG | 1.25 Gb/s | >37 dB | 100GHz with DWDM | SFP with DMI | 0 ~ 70°C | 5 to 2 dBm | -35 dBm | |
|
| SPS-73160BW-DXXG | 1.25 Gb/s | >37 dB | 100GHz with DWDM | SFP with DMI | -10 ~ 85°C | 5 to 2 dBm | -35 dBm | |
|
| SPS-73160AW-DXXG | 1.25 Gb/s | >37 dB | 100GHz with DWDM | SFP with DMI | -40 ~ 85°C | 5 to 2 dBm | -35 dBm | |
|
| SPS-73180W-DXXG | 1.25 Gb/s | >39 dB | 100GHz with DWDM | SFP with DMI | 0 ~ 70°C | 7 to 4 dBm | -35 dBm | |
|
| SPS-73180BW-DXXG | 1.25 Gb/s | >39 dB | 100GHz with DWDM | SFP with DMI | -10 ~ 85°C | 7 to 4 dBm | -35 dBm | |
|
| SPS-73180AW-DXXG | 1.25 Gb/s | >39 dB | 100GHz with DWDM | SFP with DMI | -40 ~ 85°C | 7 to 4 dBm | -35 dBm | |
|
| SPS-73200W-DXXG | 1.25 Gb/s | >41 dB | 100GHz with DWDM | SFP with DMI | 0 ~ 70°C | 8 to 5 dBm | -36 dBm | |
|
| SPS-73200BW-DXXG | 1.25 Gb/s | >41 dB | 100GHz with DWDM | SFP with DMI | -10 ~ 85°C | 8 to 5 dBm | -36 dBm | |
|
| SPS-73200AW-DXXG | 1.25 Gb/s | >41 dB | 100GHz with DWDM | SFP with DMI | -40 ~ 85°C | 8 to 5 dBm | -36 dBm | |
