| Product Number | Bit Rate | SONET /SDH |
Reach | Wavelength | Package | Temperature Range |
TX Power | RX Sens. | Data Sheet |
| SPM-9100G | 2.5/1.25 Gb/s | 150/30 0m | 850 nm | LC SFP | -10 ~ 85°C | -2.5 to -9 dBm | -15 dBm |  |
|
| SPM-9100AG | 2.5/1.25 Gb/s | 150/300 m | 850 nm | LC SFP | -40 ~ 85°C | -2.5 to -9 dBm | -15 dBm | |
|
| SPM-9100WG | 2.5/1.25 Gb/s | 150/300 m | 850 nm | LC SFP with DMI | -10 ~ 85°C | -2.5 to -9 dBm | -15 dBm | |
|
| SPM-9100AWG | 2.5/1.25 Gb/s | 150/300 m | 850 nm | LC SFP with DMI | -40 ~ 85°C | -2.5 to -9 dBm | -15 dBm | |
SFP SM LC
| Product Number | Bit Rate | SONET /SDH |
Reach | Wavelength | Package | Temperature Range |
TX Power | RX Sens, | Data Sheet |
| SPS-9102G | 2.488 Gb/s | SR/I-16 | 2 km | 1310 nm | LC SFP | -10 ~ 85°C | -3 to -9.5 dBm | -18 dBm | |
| SPS-9102AG | 2.488 Gb/s | SR/I-16 | 2 km | 1310 nm | LC SFP | -40 ~ 85°C | -3 to -9.5 dBm | -18 dBm | |
| SPS-9115G | 2.488 Gb/s | IR-1/S-16.1 | 15 km | 1310 nm DFB | LC SFP | 0 ~ 70°C | 0 to -5 dBm | -18 dBm | |
| SPS-9115BG | 2.488 Gb/s | IR-1/S-16.1 | 15 km | 1310 nm DFB | LC SFP | -10 ~ 85°C | 0 to -5 dBm | -18 dBm | |
| SPS-9115AG | 2.488 Gb/s | IR-1/S-16.1 | 15 km | 1310 nm DFB | LC SFP | -40 ~ 85°C | 0 to -5 dBm | -18 dBm | |
| SPS-9340G | 2.488 Gb/s | IR-2/S-16.2 | 40 km | 1550 nm DFB | LC SFP | 0 ~ 70°C | 3 to -2 dBm | -20 dBm | |
| SPS-9340BG | 2.488 Gb/s | IR-2/S-16.2 | 40 km | 1550 nm DFB | LC SFP | -10 ~ 85°C | 3 to -2 dBm | -20 dBm | |
| SPS-9340AG | 2.488 Gb/s | IR-2/S-16.2 | 40 km | 1550 nm DFB | LC SFP | -40 ~ 85°C | 3 to -2 dBm | -20 dBm | |
| SPS-9140G | 2.488 Gb/s | LR-1/L-16.1 | 40 km | 1310 nm DFB | LC SFP | 0 ~ 70°C | 3 to -2 dBm | -28 dBm | |
| SPS-9140BG | 2.488 Gb/s | LR-1/L-16.1 | 40 km | 1310 nm DFB | LC SFP | -10 ~ 85°C | 3 to -2 dBm | -28 dBm | |
| SPS-9140AG | 2.488 Gb/s | LR-1/L-16.1 | 40 km | 1310 nm DFB | LC SFP | -40 ~ 85°C | 3 to -2 dBm | -28 dBm | |
| SPS-9380G | 2.488 Gb/s | LR-2/L-16.2 | 80 km | 1550 nm DFB | LC SFP | 0 ~ 70°C | 3 to -2 dBm | -28 dBm | |
| SPS-9380BG | 2.488 Gb/s | LR-2/L-16.2 | 80 km | 1550 nm DFB | LC SFP | -10 ~ 85°C | 3 to -2 dBm | -28 dBm | |
| SPS-9380AG | 2.488 Gb/s | LR-2/L-16.2 | 80 km | 1550 nm DFB | LC SFP | -40 ~ 85°C | 3 to -2 dBm | -28 dBm | |
| SPS-93100G | 2.488 Gb/s | 100 km | 1550 nm DFB | LC SFP | 0 ~ 70°C | 5 to 0 dBm | -28 dBm | |
|
| SPS-93100BG | 2.488 Gb/s | 100 km | 1550 nm DFB | LC SFP | -10 ~ 85°C | 5 to 0 dBm | -28 dBm | |
|
| SPS-93100AG | 2.488 Gb/s | 100 km | 1550 nm DFB | LC SFP | -40 ~ 85°C | 5 to 0 dBm | -28 dBm | |
|
| SPS-93120G | 2.488 Gb/s | 120 km | 1550 nm DFB | LC SFP | 0 ~ 70°C | 5 to 1 dBm | -30 dBm | |
|
| SPS-93120BG | 2.488 Gb/s | 120 km | 1550 nm DFB | LC SFP | -10 ~ 85°C | 5 to 1 dBm | -30 dBm | |
|
| SPS-93160G | 2.488 Gb/s | 160 km | 1550 nm DFB | LC SFP | 0 ~ 70°C | 8 to 5 dBm | -30 dBm | |
|
| SPS-9102WG | 2.488 Gb/s | SR/I-16 | 2 km | 1310 nm | LC SFP with DMI | -10 ~ 85°C | -3 to -9.5 dBm | -18 dBm | |
| SPS-9102AWG | 2.488 Gb/s | SR/I-16 | 2 km | 1310 nm | LC SFP with DMI | -40 ~ 85°C | -3 to -9.5 dBm | -18 dBm | |
| SPS-9115WG | 2.488 Gb/s | IR-1/S-16.1 | 15 km | 1310 nm DFB | LC SFP with DMI | 0 ~ 70°C | 0 to -5 dBm | -18 dBm | |
| SPS-9115BWG | 2.488 Gb/s | IR-1/S-16.1 | 15 km | 1310 nm DFB | LC SFP with DMI | -10 ~ 85°C | 0 to -5 dBm | -18 dBm | |
| SPS-9115AWG | 2.488 Gb/s | IR-1/S-16.1 | 15 km | 1310 nm DFB | LC SFP with DMI | -40 ~ 85°C | 0 to -5 dBm | -18 dBm | |
| SPS-9340WG | 2.488 Gb/s | IR-2/S-16.2 | 40 km | 1550 nm DFB | LC SFP with DMI | 0 ~ 70°C | 3 to -2 dBm | -20 dBm | |
| SPS-9340BWG | 2.488 Gb/s | IR-2/S-16.2 | 40 km | 1550 nm DFB | LC SFP with DMI | -10 ~ 85°C | 3 to -2 dBm | -20 dBm | |
| SPS-9340AWG | 2.488 Gb/s | IR-2/S-16.2 | 40 km | 1550 nm DFB | LC SFP with DMI | -40 ~ 85°C | 3 to -2 dBm | -20 dBm | |
| SPS-9140WG | 2.488 Gb/s | LR-1/L-16.1 | 40 km | 1310 nm DFB | LC SFP with DMI | 0 ~ 70°C | 3 to -2 dBm | -28 dBm | |
| SPS-9140BWG | 2.488 Gb/s | LR-1/L-16.1 | 40 km | 1310 nm DFB | LC SFP with DMI | -10 ~ 85°C | 3 to -2 dBm | -28 dBm | |
| SPS-9140AWG | 2.488 Gb/s | LR-1/L-16.1 | 40 km | 1310 nm DFB | LC SFP with DMI | -40 ~ 85°C | 3 to -2 dBm | -28 dBm | |
| SPS-9380WG | 2.488 Gb/s | LR-1/L-16.2 | 80 km | 1550 nm DFB | LC SFP with DMI | 0 ~ 70°C | 3 to -2 dBm | -28 dBm | |
| SPS-9380BWG | 2.488 Gb/s | LR-1/L-16.2 | 80 km | 1550 nm DFB | LC SFP with DMI | -10 ~ 85°C | 3 to -2 dBm | -28 dBm | |
| SPS-9380AWG | 2.488 Gb/s | LR-1/L-16.2 | 80 km | 1550 nm DFB | LC SFP with DMI | -40 ~ 85°C | 3 to -2 dBm | -28 dBm | |
| SPS-93100WG | 2.488 Gb/s | 100 km | 1550 nm DFB | LC SFP with DMI | 0 ~ 70°C | 5 to 0 dBm | -28 dBm | |
|
| SPS-93100BWG | 2.488 Gb/s | 100 km | 1550 nm DFB | LC SFP with DMI | -10 ~ 85°C | 5 to 0 dBm | -28 dBm | |
|
| SPS-93100AWG | 2.488 Gb/s | 100 km | 1550 nm DFB | LC SFP with DMI | -40 ~ 85°C | 5 to 0 dBm | -28 dBm | |
|
| SPS-93120WG | 2.488 Gb/s | 120 km | 1550 nm DFB | LC SFP with DMI | 0 ~ 70°C | 5 to 1 dBm | -30 dBm | |
|
| SPS-93120BWG | 2.488 Gb/s | 120 km | 1550 nm DFB | LC SFP with DMI | -10 ~ 85°C | 5 to 1 dBm | -30 dBm | |
|
| SPS-93120AWG | 2.488 Gb/s | 120 km | 1550 nm DFB | LC SFP with DMI | -40 ~ 85°C | 5 to 1 dBm | -30 dBm | |
|
| SPS-93160WG | 2.488 Gb/s | 160 km | 1550 nm DFB | LC SFP with DMI | 0 ~ 70°C | 5 to 8 dBm | -30 dBm | |
|
| SPS-93160BWG | 2.488 Gb/s | 160 km | 1550 nm DFB | LC SFP with DMI | -10 ~ 85°C | 5 to 8 dBm | -30 dBm | |
|
| SPS-93160AWG | 2.488 Gb/s | 160 km | 1550 nm DFB | LC SFP with DMI | -40 ~ 85°C | 5 to 8 dBm | -30 dBm | |
CWDM SFP SM LC
| Product Number | Bit Rate | SONET /SDH |
Power Budget | Wavelength | Package | Temperature Range |
TX Power | RX Sens. | Data Sheet |
| SPS-9340-CXX0G | 2.488 Gb/s | IR-2/S-16.2 | >18 dB | CWDM* | LC SFP | 0 ~ 70°C | 3 to -2 dBm | -20 dBm | |
| SPS-9340B-CXX0G | 2.488 Gb/s | IR-2/S-16.2 | >18 dB | CWDM* | LC SFP | -5 ~ 85°C | 3 to -2 dBm | -20 dBm | |
| SPS-9340A-CXX0G | 2.488 Gb/s | IR-2/S-16.2 | >18 dB | CWDM* | LC SFP | -40 ~ 85°C | 3 to -2 dBm | -20 dBm | |
| SPS-9380-CXX0G | 2.488 Gb/s | LR-2/L-16.2 | >28 dB | CWDM* | LC SFP | 0 ~ 70°C | 5 to 0 dBm | -28 dBm | |
| SPS-9380B-CXX0G | 2.488 Gb/s | LR-2/L-16.2 | >28 dB | CWDM* | LC SFP | -5 ~ 85°C | 5 to 0 dBm | -28 dBm | |
| SPS-9380A-CXX0G | 2.488 Gb/s | LR-2/L-16.2 | >28 dB | CWDM* | LC SFP | -40 ~ 85°C | 5 to 0 dBm | -28 dBm | |
| SPS-93100-CXX0G | 2.488 Gb/s | LR-2/L-16.2 | >31 dB | CWDM* | LC SFP | 0 ~ 70°C | 5 to 1 dBm | -30 dBm | |
| SPS-93100B-CXX0G | 2.488 Gb/s | LR-2/L-16.2 | >31 dB | CWDM* | LC SFP | -5 ~ 85°C | 5 to 1 dBm | -30 dBm | |
| SPS-93100A-CXX0G | 2.488 Gb/s | LR-2/L-16.2 | >31 dB | CWDM* | LC SFP | -40 ~ 85°C | 5 to 1 dBm | -30 dBm | |
| SPS-93120-CXX0G | 2.488 Gb/s | LR-2/L-16.2 | >33 dB | CWDM* | LC SFP | 0 ~ 70°C | 6 to 3 dBm | -30 dBm | |
| SPS-93120B-CXX0G | 2.488 Gb/s | LR-2/L-16.2 | >33 dB | CWDM* | LC SFP | -5 ~ 85°C | 6 to 3 dBm | -30 dBm | |
| SPS-93120A-CXX0G | 2.488 Gb/s | LR-2/L-16.2 | >33 dB | CWDM* | LC SFP | -40 ~ 85°C | 6 to 3 dBm | -30 dBm | |
| SPS-9340W-CXX0G | 2.488 Gb/s | IR-2/S-16.2 | >18 dB | CWDM* | LC SFP with DMI | 0 ~ 70°C | 3 to -2 dBm | -20 dBm | |
| SPS-9340BW-CXX0G | 2.488 Gb/s | IR-2/S-16.2 | >18 dB | CWDM* | LC SFP with DMI | -5 ~ 85°C | 3 to -2 dBm | -20 dBm | |
| SPS-9340AW-CXX0G | 2.488 Gb/s | IR-2/S-16.2 | >18 dB | CWDM* | LC SFP with DMI | -40 ~ 85°C | 3 to -2 dBm | -20 dBm | |
| SPS-9380W-CXX0G | 2.488 Gb/s | LR-2/L-16.2 | >28 dB | CWDM* | LC SFP with DMI | 0 ~ 70°C | 5 to 0 dBm | -28 dBm | |
| SPS-9380BW-CXX0G | 2.488 Gb/s | LR-2/L-16.2 | >28 dB | CWDM* | LC SFP with DMI | -5 ~ 85°C | 5 to 0 dBm | -28 dBm | |
| SPS-9380AW-CXX0G | 2.488 Gb/s | LR-2/L-16.2 | >28 dB | CWDM* | LC SFP with DMI | -40 ~ 85°C | 5 to 0 dBm | -28 dBm | |
| SPS-93100W-CXX0G | 2.488 Gb/s | LR-2/L-16.2 | >31 dB | CWDM* | LC SFP with DMI | 0 ~ 70°C | 5 to 1 dBm | -30 dBm | |
| SPS-93100BW-CXX0G | 2.488 Gb/s | LR-2/L-16.2 | >31 dB | CWDM* | LC SFP with DMI | -5 ~ 85°C | 5 to 1 dBm | -30 dBm | |
| SPS-93100AW-CXX0G | 2.488 Gb/s | LR-2/L-16.2 | >31 dB | CWDM* | LC SFP with DMI | -40 ~ 85°C | 5 to 1 dBm | -30 dBm | |
| SPS-93120W-CXX0G | 2.488 Gb/s | LR-2/L-16.2 | >33 dB | CWDM* | LC SFP with DMI | 0 ~ 70°C | 6 to 3 dBm | -30 dBm | |
| SPS-93120BW-CXX0G | 2.488 Gb/s | LR-2/L-16.2 | >33 dB | CWDM* | LC SFP with DMI | -5 ~ 85°C | 6 to 3 dBm | -30 dBm | |
| SPS-93120AW-CXX0G | 2.488 Gb/s | LR-2/L-16.2 | >33 dB | CWDM* | LC SFP with DMI | -40 ~ 85°C | 6 to 3 dBm | -30 dBm | |
2.5 Gb/s DWDM SFP SM LC
| Product Number | Bit Rate | SONET /SDH |
Power Budget |
Spacing / Wavelength | Package | Temperature Range |
TX Power | RX Sens. | Data Sheet |
| SPS-9350W-DXXG | 2.488 Gb/s | LR-2/L-16.2 | >20 dB | 100GHz / DWDM | SFP with DMI | 0 ~ 70°C | 5 to 2 dBm | -18 dBm | |
| SPS-9350BW-DXXG | 2.488 Gb/s | LR-2/L-16.2 | >2 0dB | 100GHz / DWDM | SFP with DMI | -10 ~ 85°C | 5 to 2 dBm | -18 dBm | |
| SPS-9350AW-DXXG | 2.488 Gb/s | LR-2/L-16.2 | >20 dB | 100GHz / DWDM | SFP with DMI | -40 ~ 85°C | 5 to 2 dBm | -18 dBm | |
| SPS-9380W-DXXG | 2.488 Gb/s | >28 dB | 100GHz / DWDM | SFP with DMI | 0 ~ 70°C | 5 to 0 dBm | -28 dBm | |
|
| SPS-9380BW-DXXG | 2.488 Gb/s | >28 dB | 100GHz / DWDM | SFP with DMI | -10 ~ 85°C | 5 to 0 dBm | -28 dBm | |
|
| SPS-9380AW-DXXG | 2.488 Gb/s | >28 dB | 100GHz / DWDM | SFP with DMI | -40 ~ 85°C | 5 to 0 dBm | -28 dBm | |
|
| SPS-93120W-DXXG | 2.488 Gb/s | >32 dB | 100GHz / DWDM | SFP with DMI | 0 ~ 70°C | 7 to 4 dBm | -28 dBm | |
|
| SPS-93120BW-DXXG | 2.488 Gb/s | >32 dB | 100GHz / DWDM | SFP with DMI | -10 ~ 85°C | 7 to 4 dBm | -28 dBm | |
|
| SPS-93120AW-DXXG | 2.488 Gb/s | >32 dB | 100GHz / DWDM | SFP with DMI | -40 ~ 85°C | 7 to 4 dBm | -28 dBm | |
|
| SPS-93160W-DXXG | 2.488 Gb/s | >35 dB | 100GHz / DWDM | SFP with DMI | 0 ~ 70°C | 8 to 5 dBm | -30 dBm | |
|
| SPS-93160BW-DXXG | 2.488 Gb/s | >35 dB | 100GHz / DWDM | SFP with DMI | -10 ~ 85°C | 8 to 5 dBm | -30 dBm | |
|
| SPS-93160AW-DXXG | 2.488 Gb/s | >35 dB | 100GHz / DWDM | SFP with DMI | -40 ~ 85°C | 8 to 5 dBm | -30 dBm | |
