| Product Number | Bit Rate | SONET /SDH |
Reach | Wavelength | Package | Temperature Range |
TX Power | RX Sens. | Data Sheett |
| SPS-9102MG | Multi-rate* | SR/I-16 | 2 km | 1310 nm | LC SFP | -10 ~ 85°C | -3 to -9.5 dBm | -18 dBm |  |
| SPS-9102AMG | Multi-rate* | SR/I-16 | 2 km | 1310 nm | LC SFP | -40 ~ 85°C | -3 to -9.5 dBm | -18 dBm | |
| SPS-9115MG | Multi-rate* | IR-1/S-16.1 | 15 km | 1310 nm DFB | LC SFP | 0 ~ 70°C | 0 to -5 dBm | -18 dBm | |
| SPS-9115BMG | Multi-rate* | IR-1/S-16.1 | 15 km | 1310 nm DFB | LC SFP | -10 ~ 85°C | 0 to -5 dBm | -18 dBm | |
| SPS-9115AMG | Multi-rate* | IR-1/S-16.1 | 15 km | 1310 nm DFB | LC SFP | -40 ~ 85°C | 0 to -5 dBm | -18 dBm | |
| SPS-9340MG | Multi-rate* | IR-2/S-16.2 | 40 km | 1550 nm DFB | LC SFP | 0 ~ 70°C | 3 to -2 dBm | -20 dBm | |
| SPS-9340BMG | Multi-rate* | IR-2/S-16.2 | 40 km | 1550 nm DFB | LC SFP | -10 ~ 85°C | 3 to -2 dBm | -20 dBm | |
| SPS-9340AMG | Multi-rate* | IR-2/S-16.2 | 40 km | 1550 nm DFB | LC SFP | -40 ~ 85°C | 3 to -2 dBm | -20 dBm | |
| SPS-9140MG | Multi-rate* | LR-1/L-16.1 | 40 km | 1310 nm DFB | LC SFP | 0 ~ 70°C | 3 to -2 dBm | -28 dBm | |
| SPS-9140BMG | Multi-rate* | LR-1/L-16.1 | 40 km | 1310 nm DFB | LC SFP | -10 ~ 85°C | 3 to -2 dBm | -28 dBm | |
| SPS-9140AMG | Multi-rate* | LR-1/L-16.1 | 40 km | 1310 nm DFB | LC SFP | -40 ~ 85°C | 3 to -2 dBm | -28 dBm | |
| SPS-9380MG | Multi-rate* | LR-2/L-16.2 | 80 km | 1550 nm DFB | LC SFP | 0 ~ 70°C | 3 to -2 dBm | -28 dBm | |
| SPS-9380BMG | Multi-rate* | LR-2/L-16.2 | 80 km | 1550 nm DFB | LC SFP | -10 ~ 85°C | 3 to -2 dBm | -28 dBm | |
| SPS-9380AMG | Multi-rate* | LR-2/L-16.2 | 80 km | 1550 nm DFB | LC SFP | -40 ~ 85°C | 3 to -2 dBm | -28 dBm | |
| SPS-93100MG | Multi-rate* | 100 km | 1550 nm DFB | LC SFP | 0 ~ 70°C | 5 to 0 dBm | -28 dBm | |
|
| SPS-93100BMG | Multi-rate* | 100 km | 1550 nm DFB | LC SFP | -10 ~ 85°C | 5 to 0 dBm | -28 dBm | |
|
| SPS-93100AMG | Multi-rate* | 100 km | 1550 nm DFB | LC SFP | -40 ~ 85°C | 5 to 0 dBm | -28 dBm | |
|
| SPS-93120MG | Multi-rate* | 120 km | 1550 nm DFB | LC SFP | 0 ~ 70°C | 5 to 1 dBm | -30 dBm | |
|
| SPS-93120BMG | Multi-rate* | 120 km | 1550 nm DFB | LC SFP | -10 ~ 85°C | 5 to 1 dBm | -30 dBm | |
|
| SPS-93160MG | Multi-rate* | 160 km | 1550 nm DFB | LC SFP | 0 ~ 70°C | 8 to 5 dBm | -30 dBm | |
|
| SPS-9102MWG | Multi-rate* | SR/I-16 | 2 km | 1310 nm | LC SFP with DMI | -10 ~ 85°C | -3 to -9.5 dBm | -18 dBm | |
| SPS-9102AMWG | Multi-rate* | SR/I-16 | 2 km | 1310 nm | LC SFP with DMI | -40 ~ 85°C | -3 to -9.5 dBm | -18 dBm | |
| SPS-9115MWG | Multi-rate* | IR-1/S-16.1 | 15 km | 1310 nm DFB | LC SFP with DMI | 0 ~ 70°C | 0 to -5 dBm | -18 dBm | |
| SPS-9115BMWG | Multi-rate* | IR-1/S-16.1 | 15 km | 1310 nm DFB | LC SFP with DMI | -10 ~ 85°C | 0 to -5 dBm | -18 dBm | |
| SPS-9115AMWG | Multi-rate* | IR-1/S-16.1 | 15 km | 1310 nm DFB | LC SFP with DMI | -40 ~ 85°C | 0 to -5 dBm | -18 dBm | |
| SPS-9340MWG | Multi-rate* | IR-2/S-16.2 | 40 km | 1550 nm DFB | LC SFP with DMI | 0 ~ 70°C | 3 to -2 dBm | -20 dBm | |
| SPS-9340BMWG | Multi-rate* | IR-2/S-16.2 | 40 km | 1550 nm DFB | LC SFP with DMI | -10 ~ 85°C | 3 to -2 dBm | -20 dBm | |
| SPS-9340AMWG | Multi-rate* | IR-2/S-16.2 | 40 km | 1550 nm DFB | LC SFP with DMI | -40 ~ 85°C | 3 to -2 dBm | -20 dBm | |
| SPS-9140MWG | Multi-rate* | LR-1/L-16.1 | 40 km | 1310 nm DFB | LC SFP with DMI | 0 ~ 70°C | 3 to -2 dBm | -28 dBm | |
| SPS-9140BMWG | Multi-rate* | LR-1/L-16.1 | 40 km | 1310 nm DFB | LC SFP with DMI | -10 ~ 85°C | 3 to -2 dBm | -28 dBm | |
| SPS-9140AMWG | Multi-rate* | LR-1/L-16.1 | 40 km | 1310 nm DFB | LC SFP with DMI | -40 ~ 85°C | 3 to -2 dBm | -28 dBm | |
| SPS-9380MWG | Multi-rate* | LR-2/L-16.2 | 80 km | 1550 nm DFB | LC SFP with DMI | 0 ~ 70°C | 3 to -2 dBm | -28 dBm | |
| SPS-9380BMWG | Multi-rate* | LR-2/L-16.2 | 80 km | 1550 nm DFB | LC SFP with DMI | -10 ~ 85°C | 3 to -2 dBm | -28 dBm | |
| SPS-9380AMWG | Multi-rate* | LR-2/L-16.2 | 80 km | 1550 nm DFB | LC SFP with DMI | -40 ~ 85°C | 3 to -2 dBm | -28 dBm | |
| SPS-93100MWG | Multi-rate* | 100 km | 1550 nm DFB | LC SFP with DMI | 0 ~ 70°C | 5 to 0 dBm | -28 dBm | |
|
| SPS-93100BMWG | Multi-rate* | 100 km | 1550 nm DFB | LC SFP with DMI | -10 ~ 85°C | 5 to 0 dBm | -28 dBm | |
|
| SPS-93100AMWG | Multi-rate* | 100 km | 1550 nm DFB | LC SFP with DMI | -40 ~ 85°C | 5 to 0 dBm | -28 dBm | |
|
| SPS-93120MWG | Multi-rate* | 120 km | 1550 nm DFB | LC SFP with DMI | 0 ~ 70°C | 5 to 1 dBm | -30 dBm | |
|
| SPS-93120BMWG | Multi-rate* | 120 km | 1550 nm DFB | LC SFP with DMI | -10 ~ 85°C | 5 to 1 dBm | -30 dBm | |
|
| SPS-93160MWG | Multi-rate* | 160 km | 1550 nm DFB | LC SFP with DMI | 0 ~ 70°C | 8 to 5 dBm | -30 dBm | |
|
| SPS-93160BMWG | Multi-rate* | 160 km | 1550 nm DFB | LC SFP with DMI | -10 ~ 85°C | 8 to 5 dBm | -30 dBm | |
|
| SPS-93160AMWG | Multi-rate* | 160 km | 1550 nm DFB | LC SFP with DMI | -40 ~ 85°C | 8 to 5 dBm | -30 dBm | |
Multi-rate CWDM SFP SM LC
| Product Number | Bit Rate | SONET /SDH |
Power Budget | Wavelength | Package | Temperature Range |
TX Power | RX Sens. | Data Sheet |
| SPS-9340M-CXX0G | Multi-rate* | IR-2/S-16.2 | >18 dB | CWDM** | LC SFP | 0 ~ 70°C | 3 to -2 dBm | -20d Bm | |
| SPS-9340BM-CXX0G | Multi-rate* | IR-2/S-16.2 | >18 dB | CWDM** | LC SFP | -5 ~ 85°C | 3 to -2 dBm | -20 dBm | |
| SPS-9340AM-CXX0G | Multi-rate* | IR-2/S-16.2 | >18 dB | CWDM** | LC SFP | -40 ~ 85°C | 3 to -2 dBm | -20 dBm | |
| SPS-9380M-CXX0G | Multi-rate* | LR-2/L-16.2 | >28 dB | CWDM** | LC SFP | 0 ~ 70°C | 5 to 0 dBm | -28 dBm | |
| SPS-9380BM-CXX0G | Multi-rate* | LR-2/L-16.2 | >28 dB | CWDM** | LC SFP | -5 ~ 85°C | 5 to 0 dBm | -28 dBm | |
| SPS-9380AM-CXX0G | Multi-rate* | LR-2/L-16.2 | >28 dB | CWDM** | LC SFP | -40 ~ 85°C | 5 to 0 dBm | -28 dBm | |
| SPS-93100M-CXX0G | Multi-rate* | LR-2/L-16.2 | >31 dB | CWDM** | LC SFP | 0 ~ 70°C | 5 to 1 dBm | -30 dBm | |
| SPS-93100BM-CXX0G | Multi-rate* | LR-2/L-16.2 | >31 dB | CWDM** | LC SFP | -5 ~ 85°C | 5 to 1 dBm | -30 dBm | |
| SPS-93100AM-CXX0G | Multi-rate* | LR-2/L-16.2 | >31 dB | CWDM** | LC SFP | -40 ~ 85°C | 5 to 1 dBm | -30 dBm | |
| SPS-93120M-CXX0G | Multi-rate* | LR-2/L-16.2 | >33 dB | CWDM** | LC SFP | 0 ~ 70°C | 6 to 3 dBm | -30 dBm | |
| SPS-93120BM-CXX0G | Multi-rate* | LR-2/L-16.2 | >33 dB | CWDM** | LC SFP | -5 ~ 85°C | 6 to 3 dBm | -30dBm | |
| SPS-93120AM-CXX0G | Multi-rate* | LR-2/L-16.2 | >33 dB | CWDM** | LC SFP | -40 ~ 85°C | 6 to 3 dBm | -30 dBm | |
| SPS-9340MW-CXX0G | Multi-rate* | IR-2/S-16.2 | >18 dB | CWDM** | LC SFP with DMI | 0 ~ 70°C | 3 to -2 dBm | -20 dBm | |
| SPS-9340BMW-CXX0G | Multi-rate* | IR-2/S-16.2 | >18 dB | CWDM** | LC SFP with DMI | -5 ~ 85°C | 3 to -2 dBm | -20 dBm | |
| SPS-9340AMW-CXX0G | Multi-rate* | IR-2/S-16.2 | >18 dB | CWDM** | LC SFP with DMI | -40 ~ 85°C | 3 to -2 dBm | -20 dBm | |
| SPS-9380MW-CXX0G | Multi-rate* | LR-2/L-16.2 | >28 dB | CWDM** | LC SFP with DMI | 0 ~ 70°C | 5 to 0 dBm | -28 dBm | |
| SPS-9380BMW-CXX0G | Multi-rate* | LR-2/L-16.2 | >28 dB | CWDM** | LC SFP with DMI | -5 ~ 85°C | 5 to 0 dBm | -28 dBm | |
| SPS-9380AMW-CXX0G | Multi-rate* | LR-2/L-16.2 | >28 dB | CWDM** | LC SFP with DMI | -40 ~ 85°C | 5 to 0 dBm | -28 dBm | |
| SPS-93100MW-CXX0G | Multi-rate* | LR-2/L-16.2 | >31 dB | CWDM** | LC SFP with DMI | 0 ~ 70°C | 5 to 1 dBm | -30 dBm | |
| SPS-93100BMW-CXX0G | Multi-rate* | LR-2/L-16.2 | >31 dB | CWDM** | LC SFP with DMI | -5 ~ 85°C | 5 to 1 dBm | -30 dBm | |
| SPS-93100AMW-CXX0G | Multi-rate* | LR-2/L-16.2 | >31 dB | CWDM** | LC SFP with DMI | -40 ~ 85°C | 5 to 1 dBm | -30 dBm | |
| SPS-93120MW-CXX0G | Multi-rate* | LR-2/L-16.2 | >33 dB | CWDM** | LC SFP with DMI | 0 ~ 70°C | 6 to 3 dBm | -30 dBm | |
| SPS-93120BMW-CXX0G | Multi-rate* | LR-2/L-16.2 | >33 dB | CWDM** | LC SFP with DMI | -5 ~ 85°C | 6 to 3 dBm | -30 dBm | |
| SPS-93120AMW-CXX0G | Multi-rate* | LR-2/L-16.2 | >33 dB | CWDM** | LC SFP with DMI | -40 ~ 85°C | 6 to 3 dBm | -30d Bm | |
**18 Wavelength : from 1270 nm to 1610 nm , each step 20 nm
DWDM SFP SM LC
| Product Number | Bit Rate | SONET /SDH |
Power Budget |
Spacing / Wavelength | Package | Temperature Range |
TX Power | RX Sens. | Data Sheet |
| SPS-9350MW-DXXG | Multi-rate* | LR-2/L-16.2 | >20 dB | 100GHz / DWDM | SFP with DMI | 0 ~ 70°C | 5 to 2 dBm | -18 dBm | |
| SPS-9350BMW-DXXG | Multi-rate* | LR-2/L-16.2 | >20 dB | 100GHz / DWDM | SFP with DMI | -10 ~ 85°C | 5 to 2 dBm | -18 dBm | |
| SPS-9350AMW-DXXG | Multi-rate* | LR-2/L-16.2 | >20 dB | 100GHz / DWDM | SFP with DMI | -40 ~ 85°C | 5 to 2 dBm | -18 dBm | |
| SPS-9380MW-DXXG | Multi-rate* | >28 dB | 100GHz / DWDM | SFP with DMI | 0 ~ 70°C | 5 to 0 dBm | -28 dBm | |
|
| SPS-9380BMW-DXXG | Multi-rate* | >28 dB | 100GHz / DWDM | SFP with DMI | -10 ~ 85°C | 5 to 0 dBm | -28 dBm | |
|
| SPS-9380AMW-DXXG | Multi-rate* | >28 dB | 100GHz / DWDM | SFP with DMI | -40 ~ 85°C | 5 to 0 dBm | -28 dBm | |
|
| SPS-93120MW-DXXG | Multi-rate* | >32 dB | 100GHz / DWDM | SFP with DMI | 0 ~ 70°C | 7 to 4 dBm | -28 dBm | |
|
| SPS-93120BMW-DXXG | Multi-rate* | >32 dB | 100GHz / DWDM | SFP with DMI | -10 ~ 85°C | 7 to 4 dBm | -28 dBm | |
|
| SPS-93120AMW-DXXG | Multi-rate* | >32 dB | 100GHz / DWDM | SFP with DMI | -40 ~ 85°C | 7 to 4 dBm | -28 dBm | |
|
| SPS-93160MW-DXXG | Multi-rate* | >35 dB | 100GHz / DWDM | SFP with DMI | 0 ~ 70°C | 8 to 5 dBm | -30 dBm | |
|
| SPS-93160BMW-DXXG | Multi-rate* | >35 dB | 100GHz / DWDM | SFP with DMI | -10 ~ 85°C | 8 to 5 dBm | -30 dBm | |
|
| SPS-93160AMW-DXXG | Multi-rate* | >35 dB | 100GHz / DWDM | SFP with DMI | -40 ~ 85°C | 8 to 5 dBm | -30 dBm | |
