| Product Number | Bit Rate | SONET /SDH |
Power Budget | Spacing / Wavelength | Package | Temperature Range |
TX Power | RX Sens. | Data Sheet |
| SPS-3380W-DXXG | 125/155 Mb/s | LR-2/L-1.2 | >29 dB | 100GHz with DWDM | SFP with DMI | 0 ~ 70°C | 0 to -5 dBm | -34 dBm |  |
| SPS-3380BW-DXXG | 125/155 Mb/s | LR-2/L-1.2 | >29 dB | 100GHz with DWDM | SFP with DMI | -10 ~ 85°C | 0 to -5 dBm | -34 dBm | |
| SPS-3380AW-DXXG | 125/155 Mb/s | LR-2/L-1.2 | >29 dB | 100GHz with DWDM | SFP with DMI | -40 ~ 85°C | 0 to -5 dBm | -34 dBm | |
| SPS-33120W-DXXG | 125/155 Mb/s | >34 dB | 100GHz with DWDM | SFP with DMI | 0 ~ 70°C | 5 to 0 dBm | -34 dBm | |
|
| SPS-33120BW-DXXG | 125/155 Mb/s | >34 dB | 100GHz with DWDM | SFP with DMI | -10 ~ 85°C | 5 to 0 dBm | -34 dBm | |
|
| SPS-33120AW-DXXG | 125/155 Mb/s | >34 dB | 100GHz with DWDM | SFP with DMI | -40 ~ 85°C | 5 to 0 dBm | -34 dBm | |
|
| SPS-33160W-DXXG | 125/155 Mb/s | >37 dB | 100GHz with DWDM | SFP with DMI | 0 ~ 70°C | 5 to 2 dBm | -35 dBm | |
|
| SPS-33160BW-DXXG | 125/155 Mb/s | >37 dB | 100GHz with DWDM | SFP with DMI | -10 ~ 85°C | 5 to 2 dBm | -35 dBm | |
|
| SPS-33160AW-DXXG | 125/155 Mb/s | >37 dB | 100GHz with DWDM | SFP with DMI | -40 ~ 85°C | 5 to 2 dBm | -35 dBm | |
|
| SPS-33200W-DXXG | 125/155 Mb/s | >47 dB | 100GHz with DWDM | SFP with DMI | 0 ~ 70°C | 5 to 2 dBm | -45 dBm | |
|
| SPS-33200BW-DXXG | 125/155 Mb/s | >47 dB | 100GHz with DWDM | SFP with DMI | -10 ~ 85°C | 5 to 2 dBm | -45 dBm | |
|
| SPS-33200AW-DXXG | 125/155 Mb/s | >47 dB | 100GHz with DWDM | SFP with DMI | -40 ~ 85°C | 5 to 2 dBm | -45 dBm | |
|
| SPS-33240W-DXXG | 125/155 Mb/s | >50 dB | 100GHz with DWDM | SFP with DMI | 0 ~ 70°C | 8 to 5 dBm | -45 dBm | |
|
| SPS-33240BW-DXXG | 125/155 Mb/s | >50 dB | 100GHz with DWDM | SFP with DMI | -10 ~ 85°C | 8 to 5 dBm | -45 dBm | |
|
| SPS-33240AW-DXXG | 125/155 Mb/s | >50 dB | 100GHz with DWDM | SFP with DMI | -40 ~ 85°C | 8 to 5 dBm | -45 dBm | |
